TT-30
TECHNICAL DATA
- Capacity: 30 litres
- Internal dimensions: 550 x 300 x 250 mm
- Useful basket measurements: 500 x 250 x 175 mm
- External measurements: 720 x 420 x 500 mm
- Weight: 34 kg
ELECTRICAL CHARACTERISTICS
- Power Supply: 230V / 10A
- Heating element: 2x350W
ULTRASONIC CHARACTERISTICS
- Ultrasonic power: 600Wp (1200Wp-p)
- 1 ultrasonic generator with an output power of 600Wp (1200Wp-p)
- Working frequency: 40 KHz sweep system ± 2%
- 12 high-performance PZT (lead zirconate titanate) piezo-electric transducers with aluminium alloy body.
CONTROL PANEL
- General switch
- DEGAS system to degas water
- Ultrasounds timer
- Temperature selector
- Power level selector: 50% – 100%
FINISH AND ACCESORIES
- Tank made of 2 mm thick stainless stell AISI 316
- External panel in 1 mm thick fingerprint resistant steel
- 20 mm thick thermo-acoustic insulation
- Side handles integrated on the external panel
- Stainless steel basket with anchorage system for loading, unloading and draining the parts
- ½” drain ball valve
- Height-adjustable silentblock legs
- Insulated tank cover of Stainless steel with pneumatic shock absorber
