TT-75N
TECHNICAL DATA
- Capacity: 75 litres
- Internal dimensions: 650 x 390 x 470 mm
- Useful dimensions: 620 x 325 x 270 mm
- External dimensions: 1170 x 735 x 925 mm
- Weight: 130 kg
ELECTRICAL CHARACTERISTICS
- Power Supply: 240V / 400V
- Heating element: 2250W
ULTRASONIC CHARACTERISTICS
- Ultrasonic power: 1000Wp (2000W p-p)
- 1 ultrasonic generator with an output power of 1000Wp (2000W p-p)
- 1 submersible emitter with a power of 800Wp (1600Wp-p) made of 2,5 mm thick stainless steel AISI 316. The emitter contains 16 PZT (lead zirconate titanate) piezo-electric transducers with aluminium alloy body
- Working frequency: 40 KHz sweep system ± 2%
CONTROL PANEL
- 4.3” touch screen. Functional and intuitive access to ultrasound time setting, temperature and peripheric or optional systems.
- Programmable weekly calendar
- 6 outputs and 8 inputs temperature module PLC
FINISH AND ACCESORIES
- Tank made of 2 mm thick stainless steel AISI 304
- External panel in 1 mm thick fingerprint resistant steel
- 20 mm thick thermo-acoustic insulation
- Reinforced pneumatic platform for loading and unloading up to 30 kg
- 1” drain ball valve
- Height-adjustable silentblock legs
- Insulated tank cover in stainless steel with pneumatic shock absorber
- Air blow gun for drying the parts
- Integrated waterflow system. Sweeps the waste floating on the surface, keeping the cleaning equipment in perfect condition
- (Optional): Filtration system (stainless steel filter with polypropylene / polyester bag) for waste and mud
