Ultrasonic Generator SB-4K-L

Ultrasonic Generator SB-4K L

Model with power control from 10% to 100% on the front panel indicated with multicolor LED bar

AVAILABLE POWERS: from 2000Wp to 4000Wp, with automatic power tracking, and optimum working point
tracking, with three tracking modes, anti-stationary wave and anti-wave system in the tank.

AVAILABLE FREQUENCIES:
28KHz (With sweep system up to +/-1.5KHz).
40KHz (With sweep system up to +/-1.5KHz).
40-90KHz (With sweep system up to +/-1.5KHz).

Ultrasonic Generator SB-4K L

The ultrasonic generator SB-4K L is the pinnacle of high-power digital control for industrial cleaning applications. Delivering up to 4000Wp (peak power) and 2000Wrms, this robust industrial ultrasonic power supply is designed to drive large-scale emitters and submersible transducers with unmatched efficiency.

Whether integrated into a laboratory setting or a heavy-duty production line, the SB-4K L provides the stable, high-frequency energy required for the most demanding technical precision cleaning tasks.

Featuring advanced digital processing, this ultrasonic generator automatically optimizes the working point to ensure maximum cavitation regardless of tank load or temperature changes. With its versatile frequency support (28 kHz, 40 kHz, and 40-90 kHz), the SB-4K L is the most reliable ultrasonic cleaning solution for industries requiring consistent, high-intensity cleaning power 24/7.

The ultrasonic generator SB-4K L is engineered to power a wide range of industrial cleaning systems. Its high output capacity makes it the preferred industrial ultrasonic power supply for:

Heavy-Duty Degreasing: Driving large submersible transducers for automotive engine blocks and aerospace components.
Multi-Stage Lines: Seamlessly integrating into automated cleaning systems for high-volume manufacturing.
Medical & Pharmaceutical: Providing consistent power for the decontaminating of large-scale surgical trays and lab equipment.
Precision Mold Cleaning: Ensuring uniform cavitation for complex injection molds and tooling.
Customized Solutions: Perfectly compatible with TierraTech’s plate emitters and specialized tank designs.

This ultrasonic generator incorporates the latest in cavitation control technology. It operates with a Sweep System (+/- 1.5 kHz) that prevents standing waves, ensuring that the ultrasonic cleaning solution reaches every corner of the tank uniformly. Key technical highlights include:

Automatic Power Tracking: Maintains optimal performance by adjusting to changes in liquid level or temperature.
Triple Tracking Modes: Three selectable modes to find the perfect working point for any transducer configuration.
Frequency Versatility: Supports 28 kHz for heavy scrubbing, 40 kHz for standard cleaning, and high-frequency 40-90 kHz for ultra-delicate parts.
Anti-Stationary Wave System: Eliminates “cold spots” in the tank for 100% cleaning coverage.

Control and precision are at the heart of the SB-4K L ultrasonic generator. It features an intuitive HMI (Human-Machine Interface) with a multi-color LED bar that indicates power levels from 10% to 100%. For advanced integration, it offers:

PLC Connectivity: External control (Start/Stop, Sweep, Burst) via potential-free contacts or RS-485 Modbus protocol.
Burst & Degas Systems: Configurable burst modes for high-intensity pulses and a specialized Degas system to prep the ultrasonic cleaning solution for maximum efficiency.
Smart Alarms: Real-time diagnostics displayed through the HMI and rear connectors to ensure zero downtime.
